TA1, TA2, TA3, TA4, GR5, TC4, GR1, GR2, titanium foil is a high-quality metal material. The following is a detailed introduction to titanium foil: 1. Definition and specifications Titanium foil refers to titanium plates, strips, coils or sheets with a thickness of less than or equal to 0.1mm. Its width can be cut according to user needs, but the maximum width of rolled titanium foil is usually about 600mm. In addition to thickness, the specifications of titanium foil can also be measured by weight per unit area, such as g/m² or oz/ft², etc. The larger the value, the greater the thickness. 2. Characteristics and performance High strength: Titanium has a better strength-to-density ratio than other metals, so it can be made into components with high strength, good rigidity and light weight. This makes titanium foil widely used in aerospace, navigation, nuclear power and other fields, such as engines, frames, skins, fasteners and landing gear for aircraft. Excellent corrosion resistance: Titanium alloys have better corrosion resistance in humid air and seawater than stainless steel. Titanium has great resistance to pitting corrosion, acid corrosion and stress corrosion, and can resist corrosion from alkali, chloride, chlorinated organic matter, sulfuric acid, nitric acid and other substances. High and low temperature resistance: The application temperature of titanium is higher than that of aluminum alloy, and it can work for a long time at 450~500℃. At the same time, titanium alloy can still maintain its mechanical properties under low or ultra-low temperature conditions, so it is a good low-temperature structural material. Environmental protection and thermal conductivity: The thermal conductivity of titanium is lower than that of carbon steel or copper, but titanium has very good corrosion resistance, so the thickness of titanium can be greatly reduced, and the heat exchange mode is drop-by-drop condensation between titanium and steam, which reduces the heat transfer resistance and makes the thermal conductivity of titanium better. Non-magnetic: Titanium is a non-magnetic metal and cannot be magnetized in a large magnetic field. Biocompatibility: Titanium is non-toxic and compatible with blood, and is widely used in the medical field. 3. Application fields Titanium foil sheet is widely used in many fields due to its unique properties: Aerospace: Used to manufacture various parts of aircraft, such as engines, frames, skins, etc. Navigation: used to manufacture corrosion-resistant parts of ships. Nuclear power: used to manufacture corrosion-resistant and high-temperature resistant parts in nuclear reactors. Electronics:

YG6 carbide tips is a tungsten-cobalt common cemented carbide with a wide range of applications in industry. Its wear resistance and use strength are similar to those of YG8, but higher than those of YG3 and YG3X, and its toughness is also higher than them. This makes YG6 more advantageous than YG8 in terms of cutting speed. It has a bending strength of 1900MPa, a hardness of 90.5HRA, tempering stability of up to 800~900℃, and uniform hardness inside and outside. Its density is 14.6~15.0g/cm, bending strength is 1800MPa, hardness>89.5HRA, tensile strength>1450MPa, and impact toughness value is 2.6J/cm. For example, if you want to process chilled cast iron, ductile iron, gray cast iron, heat-resistant alloys, non-ferrous metals and their alloys, using YG6 carbide tip cutter is a good choice because it can semi-finish and finish these materials. In addition, YG6 is also suitable for small drawing dies, such as wire drawing dies and other stamping dies. If you want to finish workpieces such as high manganese steel, quenched steel and alloy steel, you can also consider using YG6 for semi-finishing and finishing. The chemical composition of YG6 standard YB849-75 steel is WC94, Co 6.0. Refer to the corresponding steel number International Organization for Standardization ISO standard steel number K20/K10 steel and my country’s GB standard steel number YG6. This information can help people choose the right material for their work. In short, YG6 carbide insert is a cemented carbide with excellent performance and wide application. Its advantages lie in its high wear resistance, service strength and toughness, as well as its ability to semi-finish and finish a variety of materials. In industrial production, YG6 has become one of the preferred materials for many companies. As a leading carbide tips China manufacturer, we are glad to cooperate with you. Keywords： yg6 carbide tips carbide cutting tips carbide tip inserts carbide tips manufacturers

Tungsten wire filament, a material that looks ordinary but actually has extraordinary properties, is everywhere in our lives, from the luminous filament of light bulbs to various high-precision industrial applications, tungsten filament wire plays a key role. Today, let’s take a deep look at this hard and tough “light”. Characteristics of tungsten filamentTungsten filament is a filament made of pure tungsten, usually with a diameter between 0.1 and 0.3 mm. Its appearance is silvery white, similar to lead wire, but it is not easy to oxidize at high temperatures. Its melting point is as high as 3410℃, which allows it to maintain its structural stability at extremely high temperatures. Uses of tungsten filamentDue to its excellent melting point and tensile strength, fine tungsten filament is widely used in various high-precision industrial applications. One of the most famous applications is the luminous filament of a light bulb. In a light bulb, tungsten filament acts as a conductor of current, converting electrical energy into light energy and emitting a bright light. In addition, tungsten filament is also used to manufacture various high-temperature furnaces and high-temperature testing equipment because it can maintain its strength and stability at extremely high temperatures. Production of tungsten wireThe production process of tungsten wire mainly includes two steps: first, the preparation of tungsten powder, and then the sintering and processing of tungsten powder. Chemical vapor deposition (CVD) or mechanical alloying (MA) is usually used to prepare tungsten powder. Then, the tungsten powder is sintered at high temperature to become tungsten rods, and then processed into tungsten wires of different diameters and lengths through processes such as drawing and cutting. Challenges and prospects of tungsten wire Although tungsten wire has a wide range of applications in many fields, its production and use still face some challenges. First, due to the extremely high melting point of tungsten wire, the energy consumption in its production process is relatively large. Secondly, since tungsten wire is prone to vibration under high current, it is necessary to pay attention to the control of current during use to avoid wire breakage. Nevertheless, with the continuous development of science and technology, the application prospects of tungsten wire are still very broad. For example, in the field of new energy, due to its high melting point, it is used as a connecting material in solar cells; in the field of medical devices, due to its biocompatibility and corrosion resistance, it

In the vast starry sky of material science, there is a shining star – high-purity tungsten wire. This seemingly ordinary metal wire has amazing physical properties, which makes it shine in many high-tech fields. Today, let us unveil the mystery of high-purity tungsten wire and explore how it has crossed a hundred years of time and space, from the incandescent lamp of Edison’s era to the precision world of modern surgical robots. “Hexagonal Warrior” in the material world The most commendable feature of high-purity tungsten wire is its amazing high temperature resistance. The melting point of 3410℃ makes it stand out from the crowd, which is more than twice the melting point of ordinary steel. It is this feature that makes tungsten wire an ideal filament material for incandescent bulbs at the beginning of its invention, opening a new era of human lighting revolution. In addition to high temperature resistance, pure tungsten wire also has excellent mechanical properties. The diameter is as thin as a hair but can maintain the strength of steel wire. This unique strength-to-weight ratio makes it a darling in the field of precision manufacturing. In the photovoltaic industry, the service life of diamond wire made of tungsten wire can reach 10 times that of stainless steel wire, which greatly reduces the cost of silicon wafer cutting. “Hidden Champion” of Photovoltaic Industry In the pursuit of clean energy today, the photovoltaic industry has put forward unprecedented high standards for materials. Thin tungsten wire has become a key material in the silicon wafer cutting process due to its excellent performance. Traditional stainless steel wire is easy to wear and deform during the cutting process, while tungsten wire diamond wire can maintain stable cutting accuracy, significantly improving the yield rate and production efficiency of silicon wafers. What is even more surprising is that the diameter of tungsten wire can be extremely fine, which creates conditions for the production of thinner silicon wafers. Thinning can not only save silicon material costs, but also improve the flexibility of battery cells, opening up a broader space for photovoltaic applications. It can be said that tungsten wire plays an indispensable role in the road of improving quality and reducing costs in the photovoltaic industry. Precision “nerves” in the medical field When tungsten wire technology meets modern medicine, an exciting chemical reaction occurs. Medical engineers use ultra-fine tungsten wire with a diameter of only

Industry status and price trend As a high-end high-temperature material, TZM alloy (molybdenum titanium zirconium alloy) continues to grow in demand in the aerospace, semiconductor and energy fields. The global market presents an oligopoly pattern, with major manufacturers concentrated in industrial powers such as the United States, Germany and Japan. China has achieved domestic substitution in some mid-to-high-end products. Price influencing factors: TZM Raw material fluctuations: Molybdenum prices account for 40-50% of the cost, and molybdenum price fluctuations in 2023 will significantly affect alloy prices Capacity restrictions: High-end product capacity is limited, and special specifications can reach a premium of 30-50% Application expansion: The semiconductor industry’s demand for high-purity TZM has increased by more than 15% annually In the past five years, TZM metal prices have shown a “W-shaped” trend and are currently stable at US$140-180/kg. It is expected to maintain an annual growth rate of 5-8% from 2024 to 2025. Product Core Value Analysis The high price of TZM alloy is due to its irreplaceable performance advantages: The strength at high temperature of 1200°C is twice that of conventional molybdenum alloys The recrystallization temperature is as high as 1400°C Excellent thermal conductivity (138W/(m·K)) and dimensional stability Process determines value: Process Cost coefficient Key advantage Conventional sintering 1.0x basic performance Hot isostatic pressing 1.5-2.0x Density ≥99.5% Electron beam melting 2.0-2.5x Ultra-high purity Life cycle cost advantage: Aviation parts reduce weight by 30%, and fuel efficiency is significant Semiconductor thermal field life is 5-8 times that of graphite Glass furnace maintenance cycle is extended by 2-3 times Purchase time: Prices are usually lower in Q2 each year Follow the trend of LME molybdenum futures Follow the production capacity dynamics of major manufacturers TZM alloy is a typical high-value functional material. Purchasing decisions should go beyond unit price considerations and comprehensively evaluate the full-cycle value of performance, life and service. Establishing strategic cooperation with suppliers with strong technical capabilities is an effective way to achieve cost optimization. Keywords：tzm material tzm alloy tzm metal tzm price tzm alloy price

Molybdenum wire is an essential consumable for wire cutting. It is expensive, but it is often broken by the workpiece during processing, which is really a headache! But don’t worry, today I will share a few tips to help you easily avoid the embarrassing situation of molybdenum wire being broken! 1.Use a magnet to suck the workpiece: When cutting halfway, use a magnet to suck the workpiece, which is simple and effective! 2. Fix with a clip: According to the actual processing situation, choose a suitable clip to clamp the workpiece to ensure stability. 3.Programming tips: When programming, hit the lead in the L3 direction to reduce the risk of wire breakage. 4.Cutting of oversized pieces: For large workpieces, you can leave a 0.25MM margin, knock it down with a sledgehammer, cut a large circle or square, and use a file to trim the scar. 5.Program plus D empty back to zero: After cutting to the end, pause , put molybdenum wire in the knife gap, you can put more, so as to effectively prevent the workpiece from falling directly and breaking the molybdenum wire. As long as you master these little tricks, you can greatly reduce the possibility of molybdenum wire being broken. Of course, there are still many experiences worth learning and exchanging during the processing process. As a molybdenum wire manufacturers, I hope everyone can learn more, exchange with each other, summarize experience, and make progress together! Keywords： molybdenum wire molybdenum wire factory

B30 copper-nickel alloy is a high-performance copper-based alloy. Due to its excellent corrosion resistance, high strength and good processing performance, it is widely used in petrochemical, marine engineering, pharmaceutical and other fields. This article will deeply analyze the performance and market situation of B30 copper-nickel alloy pipe from the aspects of technical parameters, industry standards, material selection misunderstandings, etc., and explore its price influencing factors. 1. Technical parameters of B30 copper-nickel alloy pipe The chemical composition of B30 copper-nickel alloy is mainly composed of copper (Cu) and nickel (Ni), usually containing about 75% copper and 20% nickel, and the rest are trace alloying elements. This composition makes it perform well in moderately corrosive environments, especially in environments containing chloride ions. According to the ASTMB929 standard, the typical performance parameters of B30 alloy are as follows: Tensile strength: ≥515MPa Yield strength: ≥275MPa Elongation: ≥30% Corrosion resistance: Excellent in seawater, brine and industrial solutions Conductivity: The conductivity is about 70%IACS (International Annealed Copper Standard) According to the AMS4965 standard, B30 alloy has good hot working properties and is suitable for cold and hot working and welding. 2. Industry standards and international market In the international market, the price of B30 copper-nickel alloy is affected by many factors, including raw material price fluctuations, market demand changes, and production costs. Here are some key points: Raw material prices: The price fluctuations of copper and nickel have a direct impact on the production cost of B30 alloy. For example, the copper price of the London Metal Exchange (LME) and the nickel price of Shanghai Nonferrous Network are important references for the global market. Market supply and demand: Investment fluctuations in the petrochemical industry directly affect the demand for B30 alloy. In recent years, with the recovery of the global energy industry, the demand for B30 alloy has increased. International trade: Due to the high production concentration of B30 alloy, the international price difference is large. For example, the price difference between the US market and the Chinese market may reach 5-10%. 3. Material selection misunderstandings When choosing B30 copper-nickel alloy, you need to pay attention to the following three common misunderstandings: Confusing alloy grades: B30 and copper-nickel alloys such as B10 have significant differences in composition and performance. When selecting materials, the alloy grade must be clarified to avoid substandard performance due to confusion. Ignoring the use environment: B30 alloy may not be as suitable as

When choosing a molybdenum rod supplier, you need to consider the following key factors: ‌1．Qualification and reputation: First, confirm whether the supplier has relevant certifications and licenses, including national mining licenses and ISO quality management system certifications. These certifications and licenses guarantee the legitimacy of the supplier and the quality of the product. In addition, checking customer reviews and feedback is also an important way to understand the true strength of the supplier, which can help buyers make more informed decisions. ‌2．Product quality and reliability: It is very important to ensure that the source of the purchased molybdenum rod raw materials is reliable. High-quality raw materials are the basis for ensuring the quality of the final product. Therefore, it is necessary to strictly control the supply chain, select manufacturers with a stable and high-quality supply of raw materials, and understand the supplier’s quality control system, including various testing standards and processes in the production process. It is also a point that cannot be ignored when choosing a supplier. ‌3．Price and service: Price transparency is one of the key factors in choosing a molybdenum rod supplier. Manufacturers with clear prices and no hidden costs should be selected, which can effectively avoid subsequent economic disputes. At the same time, excellent after-sales service and technical support are also important indicators for measuring the quality of supplier services. ‌4．Product performance and application areas‌: Molybdenum rods of different diameters have different performances. For example, for every 10mm increase in diameter, the thermal conductivity of the molybdenum rod will decrease by about 5W/m·K, but the bending strength will increase by 15%. This characteristic makes the 45mm diameter molybdenum rod an ideal choice for high-temperature hot pressing molds. ‌ In addition, there is a matching rule between the surface treatment process and the diameter. Small-diameter molybdenum rods are mostly polished, while large-diameter molybdenum rods are suitable for black oxidation. ‌ ‌5．Industry standards and specifications‌: Understanding and following relevant industry standards is the key to ensuring product quality. For example, GBT3462-2017 “Molybdenum Bars and Molybdenum Slabs” is a national standard formulated by China for molybdenum and molybdenum alloy materials, which regulates the chemical composition, physical properties, dimensional tolerances and inspection methods of molybdenum bars and molybdenum slabs. Keywords: molybdenum rod molybdenum rod supplier molybdenum rod factory molybdenum rod for sale molybdenum rod price molybdenum rod stock molybdenum rod suppliers buy molybdenum rod china molybdenum rod molybdenum rod china

As a plate made of molybdenum and copper through a specific process, molybdenum copper plate has shown wide application potential in many fields due to its unique physical and chemical properties. From the perspective of physical properties, first of all, molybdenum copper alloy inherits the high melting point characteristics of molybdenum and can maintain stable performance in high temperature environments. This feature gives it a significant advantage in fields that need to withstand high temperature environments, such as aerospace and chemical equipment. At the same time, copper, as an excellent thermal conductive material, combined with molybdenum, makes molybdenum copper alloy have excellent thermal conductivity. This feature is particularly important in fields such as electronic packaging, which can effectively improve the heat dissipation efficiency of equipment and ensure the stable operation of equipment. In addition to high melting point and good thermal conductivity, molybdenum copper alloy also has good electrical conductivity. This feature makes it have a wide range of application prospects in application scenarios that require electrical conductivity, such as electrodes and electric heating elements in the electronics industry. In addition, molybdenum copper alloy also has high strength and hardness, and can withstand large loads and stresses, which provides strong support for its use in the manufacture of high-temperature bearings and catalyst carriers. In terms of chemical properties, molybdenum-copper alloy exhibits excellent chemical stability. It can resist corrosion from most acidic and alkaline substances, which makes it widely used in the chemical industry. Whether it is the manufacture of corrosion-resistant chemical equipment or other occasions that need to withstand chemical corrosion, molybdenum-copper alloy can provide reliable protection. In summary, molybdenum-copper plate, as a high-performance alloy material, shows broad application prospects in many fields. In the field of aerospace, molybdenum-copper plate has become an important structural material and thermal protection material due to its light weight, high strength and good thermal conductivity. In the electronics industry, molybdenum-copper plate has become the preferred material in the field of electronic packaging due to its adjustable thermal expansion coefficient and good electrical and thermal conductivity. In the chemical industry, the chemical stability of molybdenum-copper plate enables it to resist corrosion and is suitable for the manufacture of various chemical equipment. In addition, molybdenum-copper plate is also used to manufacture high-temperature bearings, electrodes, electric heating elements and catalyst carriers, etc., providing strong support for scientific and technological progress and industrial upgrading in many industries. Keywords：molybdenum alloy molybdenum
